Description
36 NM with 4 kW output Radome scanner
ARPA (Automatic Radar Plotting Aids) Simplified Mode*
The simplified ARPA function helps avoid the risk of collision with other vessels or objects.
Up to five targets can be automatically tracked on the radar when a target enters the set tracking area, (or up to ten targets can be tracked when set manually).
By selecting one of the targets, the target information such as position, course, speed, CPA, TCPA and distance is displayed at the bottom of the screen. When the target enters the CPA and TCPA limits, an alarm message is displayed with an audible signal.
* Velocity and position data required.
DSC (Digital Selective Calling) information function*
When connected to a DSC transceiver and a DSC call is received, the received message is transferred to the MR-1010RII.
Up to 20 DSC messages can be displayed on the radar.
If a MOB position information is transmitted by a handheld DSC transceiver (including Icom IC-M94D) or MOB transmitter, the MR-1010RII can display the MOB waypoint on the radar to assist in search and rescue operation.
* Speed, position and DSC data required
Automatic Identification System (AIS) overlay function*
When connected to an external AIS device (including Icom IC-M605, IC-M510 AIS and IC-M506 AIS), up to 100 AIS target icons are overlaid on the radar.
By selecting an AIS icon, vessel information such as AIS class, MMSI number, vessel name, course, speed, CPA, TCPA, and distance are displayed in
bottom of the screen.
* Speed, position and AIS data required
Color TFT LCD screen and Wide viewing angle
The TFT LCD color screen provides a viewing angle of almost 180 degrees.
Screen intensity and screen color (day, night and user settings) can be adjusted directly with the “BRILL” button.
The wide screen has high-resolution characters and function icons.
In addition, the auto-hide feature zooms the radar to full size.
Optional video output unit
With an optional video output unit, UX-252, the MR-1010RII can be connected to an external display.
The same radar information can be viewed on the main unit and the external display at the same time.
TLL (Target Latitude Longitude) Mode*
The MR-1010RII can mark waypoints with icons and transfer the position data with NMEA TLL sentences to other NMEA 0183 devices, such as an external plotter.
* Velocity and position data required.
True Trail Mode*
The true navigation function cancels the movement of the ship itself and displays true moving objects, while static objects are not dragged.
Made in Japan Quality and reliability
All Icom products are checked to pass rigorous internal testing as well as environmental testing at the Wakayama Icom factory before shipment. Our world leading products and quality is a tradition.
Additional features
10.2–42V DC input to avoid over voltage damage
Two user-programmable alarm zones
Waypoint indicator*
And more
* Speed, position data required.
and waypoint.
